iDynamo 6
Mobile secure card reader authenticator for magstripe and EMV chip card transactions, and optional EMV and NFC contactless transactions, all in a sleek form factor ready for mobile payments and transactions
Mobile secure card reader authenticator
- Built for flexibility, restaurants, boutiques, and airlines will benefit from iDynamo 6, the next generation of MagTek secure card reader authenticators (SCRAs). iDynamo 6 is an SCRA with magnetic stripe, EMV contact, and optional EMV / NFC contactless reading capabilities.
On the Go and Customized
iDynamo 6 is made for mobile transactions, but it can be easily built into custom holsters or stands if needed.
Compatibility is its Middle name
iDynamo 6 has an array of models made to work with select operating systems. Select models are compatible with the Android, Windows, or iOS operating system and is connection and model dependent.
Stability and Reliability are Paramount
iDynamo 6’s universal mounting bracket uses a bracket design that attaches to the host of your choice to provide a stable swipe, dip or tap experience.
Optional Battery
- If handheld contactless transactions are not required, you can use iDynamo without the battery and have iDynamo powered by the host. If you need contactless payments, simply attached the form fitted, rechargeable battery pack and you are ready to go.
Secured by the MagneSafe Security Architecture
MagneSafe® is a digital identification and authentication architecture that safeguards consumers and their personal data. Designed to exceed PCI regulations, MagneSafe leverages strong encryption, secure tokenization, counterfeit detection, tamper recognition, data relevance and integrity, and dynamic digital transaction signatures, which together validate and protect the entire transaction and each of its components.
Perfect in places where contactless payments and mobility are needed
- Healthcare centers
- can enhance the patient experience by moving beyond
- reception with new technologies, including mobile
- solutions coupled with contactless payments.
Mobile and contactless payments in retail environments made simple
Bring your point of sale wherever it needs to go, from carry-out services to curbside pickup, accept mobile payments with contactless capability.
Payment Methods
| Magstripe secure card reader authenticator Triple Track (TK1/2/3); Bidirectional read; ISO 7810, 7811; AAMVA driver licenses |
YES
4 ips to 60 ips |
|
EMV chip contact
EMVCo L1 and L2 ISO/IEC 7816 |
YES - click here
Terminal type 21 and 24 |
|
EMV contactless
EMVCo L1 and L2, EMV Level 1 /C-2/C-3/C-4/ ISO/IEC 14443 (Type A/B) |
YES - click here
Optional battery pack is required for mobile operation |
|
NFC Contactless / Mobile Wallets
ISO/IEC 14443 | (Type A, Type B)C-6 D-PAS®, PayPass™ PayWave®, ExpressPay®, Apple Pay® |
YES |
Reliability and Operation
| MSR / SCRA swipes | 200K |
| EMV insertions | 300K |
| Operating System | iOS, Android, Windows |
| CPU and memory | Cortex M3, 1 MB memory |
| Status indicators | Wireless (Blue)
Status LED (Red/Green/Amber |
| Device Compatibility | iPad, iPhone, Android phones |
General
| Connection Method | USB Type C
USB 2.0 |
| Wireless
(Frequency 2.4 GHz) |
Certain standard wireless |
| Interface | USB Type C with high current
USB 2.0, Wireless |
| Display | NA |
| Secure Key Pad | NA |
| Optional Accessories | Optional charging stand |
| Web services | Magensa Services |
Electrical
| Charging | Rechargeable
USB 2.0 charge Charging Time:4.2Hr |
| Battery | Li-ion Polymer |
| Current and Power | Power via USB or Battery.
USB: 5 VDC |
Security and Certifications
| Compliance (FCC, CE, UL) | YES |
| Data protection 3DES encryption
RSA for L2 transaction DUKPT key management MagneSafe Security Architecture Unique, non-changeable device serial number |
YES |
| Tamper | Evident/Resistant |
Mechanical
| Dimensions
L x W x H or L x W x D |
3.94 x 3.25 x .61 in.
100 x 82.5 x 15.5mm |
| Weight | 3oz (83g) |
| Mount/Stabilizer | Optional Multi-Device Adapter |
Environmental
| Operating and storage temp | 32°F to 113°F (0°C to 45°C) |
| Operating humidity non-condensing | 5% to 90% |
