eDynamo

Accept mobile payments, digital transactions, and secure countertop payments from this versatile magnetic stripe and EMV contact chip card reader

  • features
  • specs
  • support
  • contact us

Secure Card Reader Authenticator for mPOS or Countertop Payments.

Turn your mobile iPhone, iPad, Android, or Windows devices into a carry-out, drive-thru, curbside pickup, and delivery solution or add the case for mounted countertop payment acceptance.

Add EMV Card Reading to Your Solution.

Whether accepting a traditional magnetic stripe cards or a contact EMV card, eDynamo gives merchants, banks, and organizations the ability to accept more payment types.

Mobile Card Reader with Bluetooth LE or USB Connection

Bluetooth LE gives you the freedom you need for mobile card reader payments. The low energy power consumption extends the life of the rechargeable batteries. If wireless is not preferred, then use the micro-USB cable and connect to a PC or mobile device with a USB host.

Compatible with a Variety of Operating Systems

Connect to your favorite iOS, Android, or Windows devices. Access the list of L3 certified processors, APIs, and Software Development Kits for iOS, Android, and Windows operating systems under support, to get your development started.

Handheld mPOS Card Reader or Secured Countertop Card Reader, You Decide

eDynamo has an ergonomic fit for handheld mobile. Optionally, the case gives merchants the ability to extend the length of the swipe path and mount the device where it makes sense for comfortable card reading.

MAGENSA SERVICES | Solutions as a Service

Couple eDynamo with Magensa Service Solutions for faster development, reduced PCI scope, enhanced customer experience, gift card and loyalty card processing, remote services, tokenization of card data for recurring payments, invoicing, and certified access to major processors through the Magensa Gateway.

APPLICATIONS | Payment Acceptance

eDynamo is built for versatility. Turn your mobile device into a carry-out, drive-thru, curbside pickup, and delivery secure payment solution. Or create a secure point of sale at your service representative locations.

MagneSafe Security Architecture

MagneSafe® is a digital identification and authentication architecture that safeguards consumers and their personal data. Designed to exceed PCI regulations, MagneSafe leverages strong encryption, secure tokenization, counterfeit detection, tamper recognition, data relevance and integrity, and dynamic digital transaction signatures, which together validate and protect the entire transaction and each of its components.

Standalone Touchscreen Adapter or Custom Build

eDynamo is easy to add to countertop, mobile, or unattended solutions. MagTek adapters make attaching eDynamo to off-the-shelf touchscreens easier than ever. Or work with our engineering team to create a custom solution that works best for you (minimum quantities apply).

  • Download Retail Brochure
  • Download Banking Brochure

Standard Configurations

Description P/N
Black, EMV Chip and swipe reader 21079802
Optional mounting case 21079809

General Information

Interfaces Bluetooth LE
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by MagTek is under license. Other trademarks and trade names are those of their respective owners.
USB HID
Color Black
Magstripe 3 track, ISO 7810 and ISO 7811/ AAMVA
EMV Chip EMV Level 1 contact and EMV level 2 contact
Tested Operating System USB: Windows 7, Windows 8.1, Windows 10, macOS 10.12 and above, Android 4.4.2 and above with USB OTG support
Bluetooth LE: iOS 7.1 and above, macOS 10.12 and above, Android 4.4.2 and above, Windows 8.1, Windows 10 on hosts with Bluetooth 4.0 hardware and above
Card Speed 6 inches per second to 60 inches per second
Magnetic Swipes 100k card swipes
EMV Insertions 100k card insertions

Security and Certifications

Compliance
EMV L1 Contact Click here.
EMV L2 Contact Click here.
MagneSafe Security Triple DES encryption, DUKPT key management, tokenization, authentication, dynamic data
MagnePrint Card authentication, counterfeit card detection
Tamper Resistance Tamper resistant and evident
Remote Services Via USB connection
Device Management Unique non-changeable serial number, time bound session IDs

Electrical

Power Input 5V from USB bus
Max Current Draw < 100 mA battery discharge rate when not charging ~500 mA battery charge rate when connected to USB charger

Mechanical

Dimensions 2.45 in. x 1.52 in. x 0.97 in.
(62.2 mm x 38.7 mm x 24.7 mm)
Cable Length 6 ft.
Wired Connection Micro-USB B, configured to appear as HID
Wireless Connection Types Bluetooth LE configured to appear as a GATT device
Wireless Range Minimum 30 ft. (10 m) in line-of-sight conditions

Environmental

Temperature
Operating 32°F to 113°F (0°C to 45°C)
Storage 32°F to 113°F (0°C to 45°C)
Humidity
Operating 5% to 90% without condensation at 23°C
Storage 5% to 90% without condensation at 23°C
